Visualize points and routes with GeoJSON in Amazon Quick Sight layer maps

With Amazon Quick Sight layer maps, you can now plot points and routes, like store locations across a city or flights leaving an airport. Geospatial maps help businesses spot patterns that are tied to location, like how a region is performing or where customers are concentrated. Amazon Quick Sight supports this with multiple map types, including point maps, filled maps, and layer maps. When layer maps first launched , you could upload a GeoJSON file to draw custom shape layers, such as sales territories or districts, and join those shapes to a dataset. That handled regions and boundaries well, but it didn’t cover the individual locations inside them or the routes running between them. Layer maps now support two more geometry types from the same GeoJSON workflow: Point and LineString . Points mark specific locations, such as individual store or facility sites. A LineString traces the route between locations, like a delivery path or a flight between airports. Amazon Quick Sight , the business intelligence (BI) capability of Amazon Quick , is a unified BI service. It delivers modern interactive dashboards, natural language querying, pixel-perfect reports, machine learning (ML) insights, and embedded analytics at scale. Amazon Quick brings together AI agents for business insights, research, and automation in one integrated experience, helping you work smarter and faster while maintaining security and access policies. In this post, we walk through the dataset and GeoJSON structure that layer maps require. We also explain how points and lines work in a layer map visual and when to choose each. Finally, we cover advanced techniques for controlling the viewport, layering geometries, and updating GeoJSON files programmatically. Dataset structure considerations A layer map gets its shapes from a GeoJSON file and its metrics from a Quick Sight dataset, and a shared key joins the two. How you structure each one determines what the map can show. This section covers what you need before you start and how a GeoJSON file is organized. Prerequisites The following are the prerequisites that you need before creating a layer map in Quick Sight: A GeoJSON file describing your geometry. A Quick Sight dataset holding the metrics and dimensions. A join key shared between the Quick Sight dataset and the GeoJSON file. The GeoJSON file must be saved in .geojson format, with a maximum supported file size of 100 MB. Structure of the GeoJSON file GeoJSON is a JSON-based format for describing geographic features such as points and lines. { "type": "FeatureCollection", "features": [{ "type": "Feature", "geometry": { "type": "Point", "coordinates": [88.4, 22.6] }, "properties": { "prop0": "value0" } }, { "type": "Feature", "geometry": { "type": "LineString", "coordinates": [ [88.2, 22.4], [88.9, 23.1], [89.5, 22.8], [90.1, 23.6] ] }, "properties": { "prop0": "value0" } }] } The structure of the file is as follows: FeatureCollection is the whole file. It has a type of FeatureCollection and a features array. Feature is a single map element. It carries a geometry (the shape) and a properties object, which holds the join key. geometry has a type (Point, LineString, or Polygon) and its coordinates . The coordinates hold a single [longitude, latitude] position for a Point , and an ordered list of positions for a LineString . Configuring the Quick Sight dataset and its GeoJSON In Quick Sight, when you configure a layer in a layer map visual, there are two primary settings to consider. The first is the Geometry type to visualize , which sets which geometry from the GeoJSON file renders: Points, Lines, or Polygons. A layer renders one geometry type at a time, so when a file mixes types like the preceding example, only Features of the selected type appear on the map. The second is matching the Shape file key field to the Dataset key field , which links each Feature in the GeoJSON to a row in your Quick Sight dataset. The field names don’t need to be identical, but the values do. The following two examples show this end to end, first a LineString layer and then a Point layer. Example: LineString layer Consider example data showing a flight from JFK to a destination city like Los Angeles. The GeoJSON structure for a single datapoint is configured as follows: { "type": "Feature", "geometry": { "type": "LineString", "coordinates": [ [-73.7781, 40.6413], [-85.5627, 40.6407], [-97.1415, 39.4569], [-108.1612, 37.1753], [-118.4085, 33.9416] ] }, "properties": { "route_id": "JFK-LAX" } } The corresponding row in the Quick Sight dataset contains the following information: Figure 1: Dataset row for the JFK-LAX route, keyed by route_id The route_id field is used to join the Quick Sight dataset with the GeoJSON file. The GeoJSON holds one such feature per route, and the dataset one row per route. The Geometry type to visualize is set to Lines. Figure 2: The JFK-LAX route drawn as a LineString layer Example: Point layer Consider example data showing a retail store location like Long Island City. The GeoJSON structure for a single datapoint is configured as follows: { "type": "Feature", "geometry": { "type": "Point", "coordinates": [-73.9490, 40.7447] }, "properties": { "store_id": "S-109" } } The corresponding row in the Quick Sight dataset contains the following information: Figure 3: Dataset row for a store, keyed by store_id The store_id field is used to join the Quick Sight dataset with the GeoJSON file. The GeoJSON holds one such feature per store, and the dataset one row per store. The Geometry type to visualize is set to Points. Figure 4: A store plotted as a Point layer Lines on layer map visuals Layer map visuals now support LineString geometry, connecting an ordered list of coordinates into a single path. As covered in the data structure section, each route is one feature, and its coordinates are the ordered positions the map connects in sequence. Use lines when the relationship between locations is what you want to show, such as flight paths, delivery routes, shipping lanes, or pipeline segments. The visual draws each path from the coordinates in your GeoJSON file rather than generating it from your data at load time. A field from your joined dataset can determine the line color encoding, so you can group routes by whatever that field represents. In addition to color, you can customize lines with width and opacity controls to adjust visual prominence and clarity on the map. The join key in the GeoJSON properties object ties each LineString to the dataset row behind its tooltip and color. For example, an airport operations team might map the flights leaving New York (JFK) on a given day. The GeoJSON file holds one LineString per route, keyed by a route ID that joins to the dataset. Each line starts at JFK and ends at its destination, such as Los Angeles, Chicago, or Miami. The dataset supplies the origin, destination, and carrier that show up in the tooltip. Figure 5: Flights leaving JFK drawn as LineString routes to multiple destinations Points on layer map visuals Amazon Quick Sight offers a native point map visual type that geocodes location names automatically and refreshes with your SPICE schedule or Direct Query connection. It supports dynamic point sizing, color encoding, and point styles such as cluster points and heatmap density gradients. It works best with data that changes frequently and where you want the map to respond to those changes visually. With the added support for GeoJSON point layers in layer map visuals, Quick Sight now offers a second point mapping capability with a few key differences. Layer map visual points use a uniform marker size and don’t support geocoding, so you provide explicit coordinates in the GeoJSON file. In return, you can control the viewport precisely, locking the map to an exact geographic region, and disabling panning and zooming. The following table summarizes the key differences: Feature Point map Layer map visual points Data source Latitude/longit
